Capacity: According to blister size and how many blisters in one carton, normally 50-120 cartons/min
Machine Net Weight: About 1500kg
Machine Dimension: 3100*1100*1600mm
Carton Dimension: (50-200)mm*(20-80)mm*(14-45)mm
It adopts PLC automatic control and touch screen operating system with speed adjusting by inverter.
Detection and Rejection of cartons which gets no object fed or leaflet fed.
Main transmission system gets overloading protecting device
Automatic trouble shooting, alarming and production counting functions are all programmed in the machine.
The machine gets stable performance, easy to change different sizes of products
Servo motor feeding system is apply to feed different styles of blister plate.
Max encasing speed
250-350g/㎡(according to carton size)
Dimension Rang (L*W*H)
Folded Leaflet Specification(1-4) Fold
220V 50HZ 1.5kw
The machine is suitable for blisters,cosmetics,electrical and so on with automatic leaflet folding inserting, carton opening, object cartoning, batch number embossing and cartooning sealing (hot glue sealing is an optional for the machine). It adopts PLC control with touch screen operation with all working stations equipped electronic sensor for running status monitoring. The machine can be connect to blister packaging machine as production line.
