HUALE MACHINERY CO.,LTD
MANUFACTURING HIGH QUALITY MACHINE & PROVIDING EXCELLENT AFTER SERVICE!
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HUALE MACHINERY |
| Certification: | CE ISO9001 |
| Model Number: | DPP-140E |
| Minimum Order Quantity: | 1Set |
| Price: | Negotiation |
| Packaging Details: | WOODEN BOX. |
| Delivery Time: | 30 working days after received your payment. |
| Supply Ability: | 15 Set per month |
| Product Name: | Small Alu Alu Blister Packing Machine | Output: | Max.30 Cutting/min |
|---|---|---|---|
| Max. Forming Area And Depth: | 140*110*12 | Pulling: | Step Motor Driving |
| Punch Pin: | PTFE（High Temperature Resistant, Non Stick Coating） | Detection System: | Mechanical Detection Or Visual Inspection |
| Used: | Alu-PVC Blister And Alu-Alu Blister | ||
| High Light: | Alu Alu Blister Machine,Capsule Packing Machine |
||
Pharmaceutical Industry Automatic Alu Alu Blister Packaging Machine With Cylinder
DPP-140E
|
Model |
ALU-ALU |
ALU-PVC |
|
|
Machine Body Material |
SS 304/316 |
||
|
Blanking frequency(times/min) |
15-30 |
20-45 |
|
|
Adjustable pulling length |
30-120mm |
||
|
Blister Size |
Design According To Customers’ Requirements |
||
|
Max Forming area and depth(mm) |
140*110*12 |
140*110*15 |
|
|
Air compressor(self-prepared) |
0.6-0.8Mpa ≥0.4m3/min |
||
|
Mould cooling |
(Recycle water or circulating water consumption) 40-80 L/h |
||
|
Power supply(Three phase) |
380V/220V 50HZ 3KW
|
380V/220V 50HZ 5.5KW
|
|
|
Wrapper specification (mm) |
Alu Alu Foil 150*(0.14-0.18)*(Φ400) |
PVC 150*(0.15-0.4)*(Φ400) |
|
|
Aluminum Foil:150*(0.02-0.15)*(Φ400) |
|||
|
Overall Dimension(L*W*H) (including foundation) |
2400*650*1450 |
||
|
Dimension of Each Part |
1350*650*1250(front) |
||
|
1050*650*1450(back) |
|||
|
Weight |
About 800kg |
||
Description
OVERALL SKETCH
PACKAGE
