HUALE MACHINERY CO.,LTD
MANUFACTURING HIGH QUALITY MACHINE & PROVIDING EXCELLENT AFTER SERVICE!
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HUALE MACHINERY |
| Certification: | CE ISO9001 |
| Model Number: | DPP-350A |
| Minimum Order Quantity: | 1Set |
| Price: | Negotiation |
| Packaging Details: | WOODEN BOX. |
| Delivery Time: | 30 working days after received your payment. |
| Supply Ability: | 15 Set per month |
| Product Name: | Aluminum Plastic Blister Packing Machine | Output: | Max.45cutting/min |
|---|---|---|---|
| Max. Forming Area And Depth: | 350*130*15(50mm Customized） | Pulling: | Step Motor Driving Or Servo Motor Driving |
| Control: | PLC Control | Detection System: | Mechanical Detection Or Visual Inspection |
| Plate Correspondence: | PRC System | Used: | Pill Or Capsule Or Tablet Etc. |
| High Light: | PVC Blister Packing Machine,Blister Packaging Machinery |
||
This machine is designed by requirement of "big sheet, deep bubble", it's suitable for packing capsule, tablet, penicillin bottle, oral liquid, candy and irregular shaped AL/PVC, PVC/PAPER package in medicine, food, electronic, medical instrument etc industries, also suitable for health products, light industries package.
Specifications
|
Model |
350A |
|
|
Machine Body |
Stainless Steel 304 |
|
|
Blanking frequency(times/min) |
15-45 |
|
|
Blister plats size |
Design according to customers’ requirements |
|
|
Adjustable pulling length |
30-140mm |
|
|
Max Forming area and depth(mm) |
350*200*50 (Private custom) |
|
|
Air compressor(Don't Provide) |
0.6-0.8Mpa ≥0.6m3/min |
|
|
Mould cooling (Recycle water or circulating water consumption) |
60-100 L/h |
|
|
Power supply(Three phase) |
380V/220V 50HZ 12KW |
|
|
Wrapper specification(mm) |
PVC |
350*(0.15-0.6)*(Φ400) |
|
PAP |
350*(50-100)g/m2*(Φ400) |
|
|
Overall Dimension(L*W*H)(including foundation) |
3650×850×1700 |
|
|
Dimension of Each Part |
1850×850×1700(front) |
|
|
1800×850×1650(back) |
||
|
Weight |
About 2000kg |
|
Description
Applications
The DPP-A blister packing machine is a newly packaging machine designed for machine in our company; its function has reached domestic leading level. It is suitable for capsule, tablet, big honey pill, candy, liquid, paste, one injector as well as irregular shape Al-plastic, paper-plastic composite packaging in pharmacy, healthcare, food, cosmetics, medical equipment industry etc.
OVERALL SKETCH
AFTER SERVICE:
For the big problem that you can not resolve by yourself, our engineer was available to go over seas for helping you to resolve the problem. For small problems, we can take the video and pictures to guide you how to adjust and fix the machine. We have professional after service team which could help you to resolve the problem within 24 hours.
WARRANTY
