HUALE MACHINERY CO.,LTD
MANUFACTURING HIGH QUALITY MACHINE & PROVIDING EXCELLENT AFTER SERVICE!
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HUALE MACHINERY |
| Certification: | CE ISO9001 |
| Model Number: | DPP-350A |
| Minimum Order Quantity: | 1 Set |
| Price: | Negotiation |
| Packaging Details: | WOODEN BOX. |
| Delivery Time: | 30 working days after received your payment. |
| Supply Ability: | 15 Set per month |
| Product Name: | ALU PVC Blister Packing Machine | Capacity: | Max.45cuttings/min |
|---|---|---|---|
| Used For: | Honey, Jam,etc. | Control System: | PLC Touch Screen |
| Option Parts 1: | Vision Inspection System | Power: | 50 Hz |
| Machine Color: | Silver | Material: | SS304 |
| Warranty: | 1 Year | ||
| High Light: | PVC Blister Packing Machine,Blister Packing Equipment |
||
This machine is designed by requirement of "big sheet, deep bubble", it's suitable for packing capsule, tablet, penicillin bottle, oral liquid, candy and irregular shaped AL/PVC, PVC/PAPER package in medicine, food, electronic, medical instrument etc industries, also suitable for health products, light industries package.
Features
1. Travel scope can be adjusted.
2. Mould is located by locating groove which makes it easy to change mould. The machine heats the PVC through conduction and forms it through pressing and frothing.
3.The material is fed automatically. The mould and feeder can be designed as user’s requirements.
4.Speed is shifted by step-less transducer. Adopt the interface of human-machine and PLC programmable controller, it can synchronize accurately.
5.Adopt the equipment of trace pressing, batch number printing and scarp-collecting.
6.Step Motor For Pulling material, more saving material and adjusting time.
7.The heating moulds will automatically separate when the machine stops, which contributes to protect the material between them and extend the machine’s life.
Main Technical Parameters
|
Item Model |
DPP-350A |
DPP-250A |
DPP-140A |
|
|
Cutting Frequency (ideal sizes:80*57mm) |
15-45 cutting/min |
15-45 cutting/min |
15-45 cutting/min |
|
|
Max. Forming Area and Depth |
350×130×15 |
250×120×15 |
140×110×15 |
|
|
Adjustable Scope of Travel(mm) |
30-140mm |
30-130mm |
30-120mm |
|
|
Packaging material (I.D.Φ75) |
PVC(mm) |
(0.15-0.6) ×350×(Φ400) |
(0.15-0.4) ×260×(Φ400) |
(0.15-0.4) ×160×(Φ350) |
|
PTP(mm) |
(0.02-0.15) ×350×(Φ400) |
(0.02-0.15) ×260×(Φ400) |
(0.02-0.15) ×160×(Φ350) |
|
|
Paper(mm) |
(50-100)g/㎡ ×350×(Φ400) |
(50-100)g/㎡ ×260×(Φ400) |
(50-100)g/㎡ ×160×(Φ350) |
|
|
Power |
380V 50Hz 9.5kw |
380V 50Hz 8kw |
380V 50Hz 5.5kw |
|
|
Air compression (Don't Provide) |
0.6-0.8Mpa ≥0.6m³/min |
0.6-0.8Mpa ≥0.45m³/min |
0.6-0.8Mpa ≥0.4m³/min |
|
|
Recycle water or circulating water consumption |
60-100L/h |
40-80L/h |
40-80L/h |
|
|
Overall Dimension(L*W*H)(including foundation) |
3650×850×1700 |
2900×750×1600 |
2400×650×1450 |
|
|
Dimension of Each Part |
1850×850×1700(front) |
1500×750×1600(front) |
1350×650×1250(front) |
|
|
1800×850×1650(back) |
1400×750×1450(back) |
1050×650×1450(back) |
||
|
Weight |
About 2000kg |
About 1200kg |
About 800kg |
|
Application
This machine is used in the pharmaceutical industry of capsule, tablet, and pilled foodstuff, food industry, liquid chocolate candies, chewing gum, cookies, jam, facial mask, eye of the cosmetics industry, medical device industry, needles, syringes, infusion tube and electronic component products such as aluminum-plastic, paper-plastic blister packaging.
