DPP-350A large Automatic Blister Packing Machine For Capsule / Tablet / Pill

Name: DPP-350A large Automatic Blister Packing Machine For Capsule / Tablet / Pill
Brand: HUALE MACHINERY
SKU: DPP-350A
Price: 1.00 USD
Availability: InStock
Rating: 5 (126 reviews)

Basic Information

Place of Origin:	CHINA
Brand Name:	HUALE MACHINERY
Certification:	CE ISO9001
Model Number:	DPP-350A

Minimum Order Quantity:	1 Set
Price:	Negotiation
Packaging Details:	WOODEN BOX.
Delivery Time:	30 working days after received your payment.
Supply Ability:	15 Set per month

Get Best Price Contact Now

Name:	Blister Packing Machine	Output:	Max.45cutting/min About 400000 Capsules/day
Pulling:	Step Motor Driving Or Servo Motor Driving	Control:	Imported PLC Control
Detection System:	Mechanical Detectio	Plate Correspondence:	Used For PRC System
Used:	Pill Or Capsule Or Tablet， Food Etc.
High Light:	PVC Blister Packing Machine , Blister Packaging Machinery

DPP-350A Large Automatic Blister Packing Machine For Capsule / Tablet / Pill

This machine is designed by requirement of "big sheet, deep bubble", it's suitable for packing capsule, tablet, penicillin bottle, oral liquid, candy and irregular shaped AL/PVC, PVC/PAPER package in medicine, food, electronic, medical instrument etc industries, also suitable for health products, light industries package.

Specifications

Item Model		DPP-350A	DPP-250A	DPP-140A
Cutting Frequency (ideal sizes:80*57mm)		15-45 cutting/min	15-45 cutting/min	15-45 cutting/min
Max. Forming Area and Depth		350×130×15	250×120×15	140×110×15
Adjustable Scope of Travel(mm)		30-140mm	30-130mm	30-120mm
Packaging material (I.D.Φ75)	PVC(mm)	(0.15-0.6) ×350×(Φ400)	(0.15-0.4) ×260×(Φ400)	(0.15-0.4) ×160×(Φ350)
	PTP(mm)	(0.02-0.15) ×350×(Φ400)	(0.02-0.15) ×260×(Φ400)	(0.02-0.15) ×160×(Φ350)
	Paper(mm)	(50-100)g/㎡ ×350×(Φ400)	(50-100)g/㎡ ×260×(Φ400)	(50-100)g/㎡ ×160×(Φ350)
Power		380V 50Hz 9.5kw	380V 50Hz 8kw	380V 50Hz 5.5kw
Air compression (Don't Provide)		0.6-0.8Mpa ≥0.6m³/min	0.6-0.8Mpa ≥0.45m³/min	0.6-0.8Mpa ≥0.4m³/min
Recycle water or circulating water consumption		60-100L/h	40-80L/h	40-80L/h
Overall Dimension(LWH)(including foundation)		3650×850×1700	2900×750×1600	2400×650×1450
Dimension of Each Part		1850×850×1700(front)	1500×750×1600(front)	1350×650×1250(front)
Dimension of Each Part		1800×850×1650(back)	1400×750×1450(back)	1050×650×1450(back)
Weight		About 2000kg	About 1200kg	About 800kg

Description

Blister forming, hot-sealing, lot number printing, avulsion line impressing and cutting etc all adopt mandrel orientation, each can move freely in the mandrel when shaking the hand wheel, and the bliser packing machine has staff gauge, easy to adjust and exact orientation.
Manipulator towing adopted culms double pendulum device, increased traction adjustable scope of the itinerary (it can get to 180mm), which can fit for medicine-card packaging of different sizes. The blister packing machine can registration heating, positive forming, up and down moiré, air cylinder heating sealing, automatic feeding, automatic lot number printing, automatic cutting die, easy to operate and credible running.
Forming positive pressure air distribution with mechanical punch, ensuring blister forming well, and could collocate exclusive Automatic Feeder. The blister packing machine could fit for the packaging of ampoule, needle, Xilin Bottle, big honey pill, medicine machine and some special shape etc.
Main transmission part adopts parallel axis and bevel wheel speed reducer, forming dies and hot-sealing dies and impressing dies adopt bolt orientation, with exact orientation, easy to change dies and material saving.
Detachable design make the blister packing machine can be easily carried and installed according to the requirement of user.

OVERAL SKETCH
DPP-350A large Automatic Blister Packing Machine For Capsule / Tablet / Pill 0

1: PVC feeder	2: PVC transporting roller
3: Heating box	4: Forming mechanism(the material of punch head is PTFE)
5: Medicine feeder (The manual feeding without this station)	6: Touch-screen
	7: PTP transporting roller
8: Heat-sealing mechanism	9: Trace-pressing mechanism
10: PTP feeding mechanism & scrap-collector	11: Tow mechanism
12: Blanking mechanism	13: Finished product output

DPP-350A large Automatic Blister Packing Machine For Capsule / Tablet / Pill 1

WARRANTY

Technical Support(24 hours on line support by emails, skype, MSN, mobile).
Loading inform(loading port, destination port, shipping date, CBM, weight, etc.)
Video for debugging after sent products.
Pre-maintance.
Quality guarantee for 1 year. Within warranty period, we provide spare parts for replacement free if not man-factor.
Welcome send us samples to test on our machine and we will take video for you to confirm.
Welcome visit our factory for checking machine and offer training course for your workers.
