HUALE MACHINERY CO.,LTD
MANUFACTURING HIGH QUALITY MACHINE & PROVIDING EXCELLENT AFTER SERVICE!
| Place of Origin: | China |
|---|---|
| Brand Name: | HUALE MACHINERY |
| Certification: | CE/GMP Standard |
| Model Number: | DPP-260G |
| Minimum Order Quantity: | 1Set |
| Price: | Negotiation |
| Packaging Details: | Wooden Box |
| Delivery Time: | 45 working days after received your payment |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 15 Set per month |
| Product Name: | High Speed Blister Packing Machine | Output: | Max.100cutting/min |
|---|---|---|---|
| Max. Forming Area And Depth: | 250*200*20 | Pulling: | Step Motor Driving |
| Material Consist: | SS304/316 | Control: | PLC Control |
| Detection System: | Mechanical Detection Or Visual Inspection | Used: | Pill Or Capsule Or Tablet |
| Plate Correspondence: | PRC (print Register Control) System | ||
| High Light: | Blister Pack Sealing Machine,Pharma Blister Packaging Machine |
||
Automatic Capsule High Speed Blister Packing Machine / Blister Pack Sealing Machine
Introduction:
DPP-260G flat type high speed blister packaging machine is our advanced equipment designed under updated improvement. It equipped top brand PLC controller with touch screen displayed in double languages,frequency inverter for speed control, servo traction ensure the length of blister sheet adjustable within the range.
Description:
Technical Parameters:
|
Item Model |
DPP-260G |
|
|
Cutting Frequency(ideal sizes:80*57mm) |
20-100 cutting/min |
|
|
Max. Forming Area and Depth |
250×200×20 |
|
|
Adjustable Scope of Travel(mm) |
30-220mm |
|
|
Packaging material(I.D.Φ75) |
PVC(mm) |
(0.15-0.4)×260×(Φ400) |
|
PTP(mm) |
(0.02-0.15)×260×(Φ250) |
|
|
Paper(mm) |
(50-100)g/㎡ ×260×(Φ300) |
|
|
Power |
380V 50Hz 14kw |
|
|
Air compression(self-prepared) |
0.6-0.8Mpa ≥0.25m³/min |
|
|
Recycle water or circulating water consumption |
60-100L/h |
|
|
Overall Dimension(L*W*H)(including foundation) |
5600×900×1750 |
|
|
Dimension of Each Part |
2300×720×1600(front) 1500×900×1750(middle) |
|
|
1800×900×1750(back) |
||
|
Weight |
About 2200kg |
|
Package
