Pharmaceutical Alu Plastic Alu Tropical Blister Packing Equipment Multi - Functional

China Pharmaceutical Alu Plastic Alu Tropical Blister Packing Equipment Multi - Functional supplier
Pharmaceutical Alu Plastic Alu Tropical Blister Packing Equipment Multi - Functional supplier Pharmaceutical Alu Plastic Alu Tropical Blister Packing Equipment Multi - Functional supplier Pharmaceutical Alu Plastic Alu Tropical Blister Packing Equipment Multi - Functional supplier Pharmaceutical Alu Plastic Alu Tropical Blister Packing Equipment Multi - Functional supplier Pharmaceutical Alu Plastic Alu Tropical Blister Packing Equipment Multi - Functional supplier

Large Image :  Pharmaceutical Alu Plastic Alu Tropical Blister Packing Equipment Multi - Functional

Product Details:

Place of Origin: China
Brand Name: HUALE MACHINERY
Certification: CE/GMP Standard
Model Number: DPP-250F

Payment & Shipping Terms:

Minimum Order Quantity: 1Set
Price: $15000-$20000 USD/Set
Packaging Details: Wooden Box
Delivery Time: 45 working days after received your payment
Payment Terms: T/T or L/C
Supply Ability: 15 Set per month
Contact Now
Detailed Product Description
Product Name: ALU PVC ALU BLISTER PACKING MACHINE Output: Max.30cutting/min
Max. Forming Area And Depth: 250*120*15 Mould Cooling: 60-100L/h
Capacity Of Air Compressor: 0.6-0.8Mpa ≥0.5m3/min Power Supply: 380V/220V 50HZ 11.5KW



Pharmaceutical Muti-functional Alu Plastic Alu Tropical Blister Packing Machine





Application

This machine mount up forming and sealing of tropical aluminum on the basis of 250
blister packing machine.It takes sealing, moisture-proof and light-avoiding enhance the
value product.It is widely used to pack all kinds of products in pharmacy, food,
medical health products.

The machine suitable for blister packing with Alu-Plastic, Alu-Alu and Alu-Plastic-Alu.


Pharmaceutical Alu Plastic Alu Tropical Blister Packing Equipment Multi - Functional

Main feature

1). Adopts the elements of 250 blister packing machine, machine tool track type machine
basis, ease of adjusting, and the mould position can be adjusted and accurately

2). It adopt body division machanism to avoid inconvenience of transfer due to the length
of the bofy 1.8 m by mounting up the forming and sealinassmbly.

3) This machine use servo double drive strucyure, it can avoid synchronized bubble break
cause by sudden machine stop.It also can conveniently realize photocell register function,
and servo air clip clip drive function.At the meanwhile, it also fastens the adjustment caused during mould change.Tith this strecture, you can also set the dive distance on human-machine interface.



Specifications



Model

ALU-Plastic-ALU

ALU ALU

ALU-PVC

Machine Body

Stainless Steel 304 (medicinal contact can be selected SS3016)

Blanking frequency

(times/min)

(Standard size 57*80)

12-30

15-30

20-45

Adjustable pulling length

30-120mm

Blister Plate Size

Design According To Customers’ Requirements

Max Forming area and depth

(mm)

250*120*15

250*120*13

250*120*15

Power supply(Three phase)



380V/220V 50HZ 11.5KW

380V/220V 50HZ 4.5KW

380V/220V 50HZ 8KW

Packaging Material (mm)

(I.D.Φ75mm)

Tropical Foil

260*(0.1-0.12)*(Φ400)

PVC

260*(0.15-0.4)*(Φ400)

Alu Alu Foil

260*(0.14-0.18)*(Φ400)

PVC

260*(0.15-0.4)*(Φ400)

Blister Foil: 260*(0.02-0.15)*(Φ250)

Air compressor

0.6-0.8Mpa  ≥0.5m3/min (self-prepared)

Mould cooling

(Recycle water or circulating water consumption) 60-100 L/h

Overall Dimension(L*W*H)

4450*800*1600(including foundation)

Dimension of Each Part

1400*800*1600(front)

1650*800*1450(middle)

1400*800*1450(back)

Weight

About 1700kg
