Pharmaceutical Mini Lab Blister Packaging Machinery DPP-88H PC Circuit Panel Control

China Pharmaceutical Mini Lab Blister Packaging Machinery DPP-88H PC Circuit Panel Control supplier
Pharmaceutical Mini Lab Blister Packaging Machinery DPP-88H PC Circuit Panel Control supplier Pharmaceutical Mini Lab Blister Packaging Machinery DPP-88H PC Circuit Panel Control supplier Pharmaceutical Mini Lab Blister Packaging Machinery DPP-88H PC Circuit Panel Control supplier

Large Image :  Pharmaceutical Mini Lab Blister Packaging Machinery DPP-88H PC Circuit Panel Control

Product Details:

Place of Origin: China
Brand Name: HUALE MACHINERY
Certification: CE/GMP Standard
Model Number: DPP-88H

Payment & Shipping Terms:

Minimum Order Quantity: 1Set
Price: 5000-6000 usd/set
Packaging Details: 1.The machine will not be shaking in transport with wooden fixed. 2.The machine will not be affected with damp in transport with packed with PE plastic bags. 3.Easy shaking station will fixed with hard rope. 4.Long machine will packed separately. 5.If ther
Delivery Time: 30 working days after received your payment
Payment Terms: T/T or L/C
Supply Ability: 15 Set per month
Contact Now
Detailed Product Description
Product Name: Small Blister Packing Machine Output: Max.30cutting/min
Max. Forming Area And Depth: 100*90*15 Material Consist: SS304/316
Control: PC Circuit Panel Detection System: Mechanical Detection Or Visual Inspection
Power: 220V 50Hz 4.5Kw Cooling: 30-50L/h



Pharmaceutical Mini Lab Blister Packing Machine DPP-88H factory supply





Specifications



  1. using air clip to tow material
  2. operated by PC circuit panel
  3. speed controlled by transducer
  4. forming tray, filling in tray and sealing tray functions etc.
  5. The feeder can be changed as your request.
  6. CE ISO Certification.



Techincal Parameter



Item Model

DPP-88H

Cutting Frequency

10-30times/min

Max. Forming Area and Depth

100×90×15mm

Adjustable Scope of Travel

40-100mm

Packaging material(I.D.Φ75)

PVC(mm)

(0.15-0.4)×110×(Φ300)

PTP(mm)

(0.02-0.15)×110×(Φ250)

PET(mm)

(50-100)g/m2×110×(Φ300)

Power

220V  50Hz  4.5k

Air compression(self-prepared)

0.6-0.8Mpa≥0.3m³/min

Recycle water or circulating water consumption

 30-50L/h

Overall Dimension(L*W*H)

1700×450×1100(including foundation)

Weight

About 300kg













Description



1. Pulling length can be adjusted. Mold is located by located groove so that it's easy to change mold. The
machine heats the PVC through conduction and forms it through pressing and frothing.
2. The material is fed automatically. The mold and feeder can be designed as user's requirements.
3. The heating molds will automatically separate when the machine stops, which contributes to protect the material from heated moulds.
4. The machine comes with Perforation embossing, batch number embossing and wasted material rewinding.
5. Air Clip forward and backward cycling running for pulling the packing material.
6. Speed is controlled by inverter while operation on touch panel.





Machine details



Pharmaceutical Mini Lab Blister Packaging Machinery DPP-88H PC Circuit Panel Control





WARRANTY

  1. Technical Support(24 hours on line , skype, wechat, whatsapp).
  2. Loading inform(loading port, destination port, shipping date, CBM, weight, etc.)
  3. Video for debugging after sent products.
  4. Pre-maintance.
  5. Quality guarantee for 1 year. Within warranty period, we provide spare parts for replacement free if not man-factor.
  6. Welcome send us samples to test on our machine and we will take video for you to confirm.
  7. Welcome visit our factory for checking machine and offer training course for your workers.
