CE Energy Saving Blister Pack Sealing Machine Tablets / Pills / Capsules Use

China CE Energy Saving Blister Pack Sealing Machine Tablets / Pills / Capsules Use supplier
CE Energy Saving Blister Pack Sealing Machine Tablets / Pills / Capsules Use supplier CE Energy Saving Blister Pack Sealing Machine Tablets / Pills / Capsules Use supplier CE Energy Saving Blister Pack Sealing Machine Tablets / Pills / Capsules Use supplier CE Energy Saving Blister Pack Sealing Machine Tablets / Pills / Capsules Use supplier CE Energy Saving Blister Pack Sealing Machine Tablets / Pills / Capsules Use supplier

Large Image :  CE Energy Saving Blister Pack Sealing Machine Tablets / Pills / Capsules Use

Product Details:

Place of Origin: China
Brand Name: HUALE MACHINUARY
Certification: CE/ ISO9001
Model Number: DPP-250A

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD $1000-14000/set
Packaging Details: packed in plastic bag and fixed in export wooden box.
Delivery Time: 30 working days after received your payment
Supply Ability: 20 Sets per month
Contact Now
Detailed Product Description
Machine Name: Flat Type Aluminum Plastic Blister Packing Machine Packaging Material: Aluminum Foil PVC Or PVC Heating Sealing Paper
Puching Frequnency: 45cutting/min Max Forming Area And Depth: 250*120*15mm
Blister Plate Size: Design According To Customer's Requirement Machine Weight: About 1200kg



CE approved energy saving equipment automatic blister wrapping machine for tablets,pills,capsules





Introductions:

This machine is suitable for kinds of products packaging and it is easy to operate. The machine is suitable for aluminum foil(PTP), PVC or paper PVC blister packaging.

It adopts the interface of human-machine and PLC control system.



Performance and characteristics:

The machine heats the PVC through heated board and forms by compressed air frothing.



The heating mold will automatically separate when the machine stops, which can protect the packing material from heated mould.



Adopt Step motor for precise controlling the pulling length and saving packing material.



Functions for cutting line embossing, batch number embossing and wasted packaging material rewinding.



Mold and feeder can be designed according to customer’s requirement.



TECHNICAL PARAMETER





Item Model

DPP-250A

Cutting Frequency(ideal sizes:80*57mm)

15-45 cutting/min

Max. Forming Area and Depth

250×120×15mm

Adjustable Scope of Travel(mm)

30-130mm

Packaging material(I.D.Φ75)

PVC(mm)

(0.15-0.4)×260×(Φ400)

PTP(mm)

(0.02-0.15)×260×(Φ400)

Paper(mm)

(50-100)g/㎡

×260×(Φ400)

Power

380V  50Hz 8kw

Air compression(self-prepared)

0.6-0.8Mpa≥0.45m³/min

Recycle water or circulating water consumption

 40-80L/h

Overall Dimension(L*W*H)(including foundation)

2900×750×1600

Dimension of Each Part

1500×750×1600(front)

1400×750×1450(back)

Weight

About 1200kg





Machine Details



NEW FEEDER

  • Under the control of the quantity of material, can keep the disc brushing not too full, filling the products more accurately
  • Moderate material can keep PVC not deformated, make machine operate more stable



CE Energy Saving Blister Pack Sealing Machine Tablets / Pills / Capsules Use





WARRANTY

  1. Technical Support(24 hours on line trademanager, skype, MSN, mobile).
  2. Loading inform(loading port, destination port, shipping date, CBM, weight, etc.)
  3. Video for debugging after sent products.
  4. Pre-maintance.
  5. Quality guarantee for 1 year. Within warranty period, we provide spare parts for replacement free if not man-factor.
  6. Welcome send us samples to test on our machine and we will take video for you to confirm.
  7. Welcome visit our factory for checking machine and offer training course for your workers.
